Ritmo Compact 630 Butt Fusion Machine Ø 280-630 mm

Brand: Ritmo
Category: Butt Fusion Machines

Product details

Compact 630 welds Ø 280-630 mm. Its 235 kg detachable body positions far more easily around a site than the fixed machines that normally cover these diameters. What sets the Compact line apart is that the two-clamp machine body detaches from the frame, so the joint can be made on the ground, suspended or in confined space. The electro-hydraulic gearcase sits in a protective box and supports Dual Pressure mode. The Teflon-coated heating plate is held by the Digital Dragon thermoregulator, and the electric milling cutter carries a safety microswitch and motor overload protection.

Technical specifications

Working range	280 ÷ 630 mm; 10” IPS ÷ 24” IPS; 10’’ DIPS ÷ 20” DIPS
Power supply	230 V 3-Phase 50/60 Hz; 400 V 3-Phase 50/60 Hz
Total absorbed power	12350 W
Suggested power generator	12 kVA
Working temperature	180° ÷ 280° C (356° ÷ 536° F)
Outside temperature range	-10° ÷ 40° C (14° ÷ 104° F)
Time to reach welding temperature	~< 20’ minutes
Dimensions Body machine (W x D x H)	1120x1088x852 mm (44 x 43 x 33.6 in)
Dimensions gearcase (W x D x H)	320x620x485 (12.6 x 24.4 x 19 in)
Weight Body machine	235 Kg (518 Ib)
Weight standard composition	490 Kg (1080.3 Ib)
